【节能固化机】PCB行业电子电源双波峰uv设备SK-408-700LS

品牌：SunKun(三昆)

型号：SK-408-700LS

订购：不限数量

价格：面议

⒈订购热线：13823369867(李先生)
1753480168
⒉业务咨询：18123855293(蒋小姐)
2851085006



⒈市场部：13510246266(黄总经理)
289604232

1、UV灯功率:6.0kw*2支、8kw*2支(卤素灯)
2、UV灯总长:800mm、弧长:700mm
3、UV波段主波峰:365nm、380nm
4、UV灯累时器配置
5、强弱光强调节:20%~100%(采用电子电源无级调节)
6、钣金灯箱安装进口插片反射器
7、采用上、下排风系统
8、输送材料:聚四氟和不锈钢滚轮
9、输送宽度:700mm
10、输送速度:0~5m/min
11、入口高度:50mm
12、电源:380VAC 50HZ

1, UV lamp power: 6.0kw * 2, 8kw * 2 (halogen)
2, the total length of the UV lamp: 800mm, arc length: 700mm
3, UV band main peak: 365nm, 380nm
4, UV light timer configuration
5, strong and weak light intensity adjustment: 20% ~ 100% (using electronic power supply stepless adjustment)
6, sheet metal light box installation of imported insert reflector
7, using the upper and lower exhaust system
8, conveying materials: polytetrafluoroethylene and stainless steel rollers
9, conveying width: 700mm
10, conveying speed: 0~5m/min
11, the entrance height: 50mm
12, power: 380VAC 50HZ

主要用途：
1、主要适用于VU喷涂、五金、丝印、玻璃、塑胶、表面上光处理、uv油墨、涂料实验等。UV能量高,涂膜穿透能力强;

本机特点：
1、聚光型设计,高聚光反光灯罩,瞬时干燥,速度特快;
2、灯箱内设计的通风系统;
3、各灯皆可调节上下;
4、输送带调速,输送速度平稳可调;
5、传动网带调整装置,以免跑偏;
6、灯管异常保护装置。

The main purpose:
1, mainly for VU spraying, hardware, silk screen, glass, plastic, surface glazing, uv ink, coating experiments. High UV energy and strong penetrating ability of coating film;

This machine features:
1. Concentrating design, high concentration reflector, instant drying, fast speed;
2. The ventilation system designed in the light box;
3, each lamp can be adjusted up and down;
4. Conveyor belt speed regulation, conveying speed is stable and adjustable;
5, the transmission network with adjustment device to avoid deviation;
6. Lamp abnormal protection device.
